Screened PUR UL control 3G2.5

Benefits

• Increased durability under harsh conditions thanks to robust PUR outer sheath
• Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
• Certified for the USA and Canada for export-oriented machine, appliance and apparatus manufacturers
• Copper braiding screens the cable against
  electromagnetic interference

Application range

• Appliance and apparatus construction
• Industrial machinery and machine tools
• Measurement, control and electrical applications
• Very suitable for oily wet areas within machinery and production lines that are subject to normal mechanical stress
• Under consideration of the temperature range also suitable for outdoor use

Product features

• High oil-resistance
• Flame-retardant
• Abrasion and notch-resistant
• UV-resistant according to ISO 4892-2
• Resistant to hydrolysis and microbes

Norm references / Approvals

• UL AWM Style 20234
• cUL AWM I/II A/B
• UL File No. E63634

Product Make-up

• Fine-wire, bare copper conductor
• Core insulation: special PVC
• Cores twisted in layers
• Plastic foil wrapping
• Tinned-copper braiding
• Special polyurethane outer sheath (PUR)
• Sheath colour: black (similar RAL 9005)

Nominal voltage

• U0/U: 300/500 V
• UL/CSA: 1000 V

Test voltage

• 4000 V

Protective conductor

• G = with GN-YE protective conductor
• X = without protective conductor

Temperature range

• Occasional flexing: -5°C to +70°C (UL: +80°C)
• Fixed installation: -40°C to +80°C

SKU

LAPP-1321403
