SKL - 44–56mm clamp

SKL - EMC shield clamp range 44–56mm (clamp only)

Free shipping on Web orders over $100

$65.00
(5 Pack excl GST)
On Request
SKU: ICO-36216 Manufacturer part number: 36216 Manufacturer: icotek

EMC shield clamps, single for direct mounting via rivets

EMC shield clamps are used, where the shield of cables must be connected to the earth potential. They are easy to use and effective in earthing single cable shields.

The EMC cable clamps offer a large contact area to the cable shield. In comparison to conventional shielding brackets an up to 50% higher contact area can be achieved when using icotek EMC shield clamps. The specified clamping range can be exceeded up to 10%.

Due to its special design the clamping ranges of the MSKL are very large while the dimensions are comparatively small. (Example: MSKL 3-12, assembled with a 12 mm cable shield: width 26.25 mm).

The shield clamps can be easily attached via rivet.

Specifications

  • Material Shield clamp spring steel, zinc plated
  • Mounting options riveting
  • Mounting location universal

Advantages & benefits

  • Large contact area
  • Shield contact and strain relief separated
  • The spring design requires no adjustments and will permanently maintain contact to the cable shield
  • Space-saving design, even when fully assembled
  • MSKL Large clamping areas, therefore less product sizes needed to cover a large cable diameter range
  • Shock and vibration resistant, maintenance free



SKU ICO-36216
MPN 36216
EAN 4251269322754

We strive to provide you with the best information we can, considering the images are not to scale and do not represent detailed perspectives of the respected products. If you notice any errors or omissions in this information, please let us know using the contact us tab on this page.
*
*
*
