CAT7A Marine 4x(2x23 AWG/7)

SH-DATA Ethernet Cat.7A 4x(2x23 AWG/7) S/FTP

$12.80
(Per/m excl GST)
On Request
Select or Type Quantity
SKU: LAPP-NP902CH Manufacturer part number: NP902CH Price breaks available:

Free shipping on Web orders over $100

SH-DATA Ethernet Cat.7A

Ethernet cable approved for marine and offshore use

  • Marine/offshore approved Ethernet cable.
  • Category 7A construction intended for high-performance, low-noise networking in harsh environments.
  • Shielding architecture (pair foil + overall braid) helps reduce EMI and improve signal integrity.
  • Fire-safety focused design: flame propagation tests, low smoke emission, and halogen-related requirements are listed.
  • Two jacket compound options (SHF1 / SHF2) to match installation needs; SHF2 adds stronger environmental/chemical resistance (oil/salt water/weathering).

Construction details

  • Conductor: stranded bare copper (7 strands).
  • Insulation: foam-skin polyethylene (EN 50290-2-23 referenced).
  • Pair colors: white/blue-blue, white/orange-orange, white/green-green, white/brown-brown.
  • Pair screen: aluminum/polyester tape (aluminum surface outside).
  • Assembly: shielded pairs stranded together.
  • Overall shield: tinned copper braid with 85% coverage.
  • Outer jacket: SHF1 or SHF2 compound (IEC 60092-360 referenced); colors listed include grey (SHF1) and black (SHF2).

Fire behaviour and safety standards listed

  • IEC 60332-3-22 (bunched cable / no fire propagation).
  • IEC 60332-1-2 (single cable / no flame propagation).
  • IEC 60754-1 and IEC 60754-2 (halogen content and halogen-related conductivity).
  • IEC 61034 (smoke emission / smoke density).

Chemical and environmental resistance

  • SHF1: UV resistant according to UL 758 (datasheet notes protection recommendations for contact with salty water/nebulation).
  • SHF2: UV resistant (UL 758) and oil resistant (UL 758); also references IEC 60092-360 table 9.10 for resistance to salty water and weathering.
  • Temperature range: -15°C to +90°C (SHF1) and -40°C to +90°C (SHF2).
  • Minimum bending radius: 10x outer diameter.

Key electrical characteristics

  • Max DC conductor resistance at 20°C: 74.5 Ω/km (23 AWG).
  • Capacitance: 45 pF/m (23 AWG).
  • Characteristic impedance (1–100 MHz): 100 Ω (±15%).
  • Voltage rating: 125 V.
  • Minimum insulation resistance: 5.0 GΩ·km.
  • Nominal velocity of propagation (100 MHz): 77%.
  • Nominal attenuation: 600 MHz = 66.1/49.5/47.6 dB/100m.

Key mechanical characteristics

  • Nominal weight: 92 kg/km (23 AWG).
  • Nominal outer diameter: 8.4 mm (23 AWG).

Standards referenced

  • EN 50173.
  • EN 50288-4-2.
  • IEC 61156-6.
  • TIA/EIA 568 B.2.
  • ISO/IEC 11801.



SKU LAPP-NP902CH
MPN NP902CH

We strive to provide you with the best information we can, considering the images are not to scale and do not represent detailed perspectives of the respected products. If you notice any errors or omissions in this information, please let us know using the contact us tab on this page.
Products specifications
Attribute name Attribute value
Number of Conductors 8
Number of Pairs 4
Conductor Size 23 AWG
