Noark MCCB 2P 500Vdc 80A

Noark Ex9MD1B Resettable DC Circuit Breaker, 500V (250V x 2-Pole), 80A

High Current, Non-Polarised

Used primarily on battery banks, the Noark Ex9MD range of Resettable Circuit Breakers (MCCBs) provide a more serviceable approach to protection than standard NH fuses and provide high current breaking capabilities for DC circuits.

Features:

• High breaking capacity
• Installation flexibility
• Field installable accessories
• Certified to EN 60947

Specifications

• Current Rating:  80A
• Number of Poles: 2
• Voltage Per Pole: 250Vdc
• Total Voltage: 500Vdc

DC switching voltage 250V DC per pole e.g. 2 pole = 500V DC

SKU:  PV-28707
MPN: 28707
Type: EX9MD1B TM DC80 2P
