Unarmoured Single Core 1x10 Black

SH-W 1x10 Black RAL9005

Free shipping on Web orders over $100

POA

On Request

SKU: LAPP-N001DB Manufacturer part number: N001DB

There is currently an issue with our stock Please contact us for more information

Overview
Downloads
Ask A Specialist

SH-W Single Core Cables

SH-W single core cables are designed for switchboard panels and internal wiring applications. They are available in various cross-sections with different voltage ratings to suit a wide range of installation requirements.

These single core cables offer reliable performance and safety for internal wiring and switchboard applications. They are constructed with tinned copper (or optional bare copper) conductors and HF XLPE insulation, ensuring excellent electrical properties, fire resistance, and low smoke emission. Compliant with relevant IEC standards, SH-W cables provide a durable and safe solution for demanding electrical installations.

Technical Data

Conductor: Tinned copper (optional bare copper), Class 5 according to IEC 60228
Insulation: HF XLPE compound according to IEC 60092-360. Thickness according to IEC 60092-353 and IEC 60092-376
Marking: For cross-sections 0.50 and 0.75 mm²: UNIKA (Italy) – SH-W 150/250 V 90°C cross-section – IEC 60092-376 – IEC 60332-1-2 – traceability code
For cross-sections 1 mm² and above: UNIKA (Italy) – SH-W 0.6/1 kV 90°C cross-section – IEC 60092-353 – IEC 60332-1-2 – traceability code
Rated Voltage: 150/250 V for cross-sections 0.50 and 0.75 mm²
0.6/1 kV for cross-sections 1 mm² and above
Rated Conductor Temperature: 90 °C
Fire Behaviour: IEC 60332-1-2 not flame propagation
IEC 60754-1 halogen content
IEC 60754-2 pH and conducibility
IEC 60684-2 fluorine content
IEC 61034-1 and 61034-2 Smoke emission

SKU LAPP-N001DB
MPN N001DB

We strive to provide you with the best information we can, considering the images are not to scale and do not represent detailed perspectives of the respected products. If you notice any errors or omissions in this information, please let us know using the contact us tab on this page.
