MC4 Solar Cable Connectors

Original MC4 Solar Cable Connectors

The Original, Multi Contact (MC4) Solar Cable Connector by Stäubli

Mitigate power loss, downtimes, service hours, risk of fire of your PV-System by using Original MC4 connectors. The unique MULTILAM contact technology will guarantee an excellent long-term reliability and a low contact resistance over the entire product life.

  • Tried and tested for 12 years of experience in the field
  • Snap-in locking by safety clip, PV-SSH4 in accordance with NEC 2011, can be released only with tool
  • Proven MULTILAM technology with high long-term stability, which ensures consistently low performance loss throughout the entire service life
  • Available for assembly with cross-sections of 10mm²
  • Also available as pre-harnessed leads made to order
View as
Display per page
Filter by attributes

MC4 Solar Connector Set 100pcs

MC4 Solar Connector Set 50 x MC4 Male + 50 x MC4 Female
MC-MC4-SET-50

MC4 Female Socket 4mm

MC4 Female Socket to suit 4-6mm² cable (5-6mm OD) with contact pin
MC-320014

MC4 Male Plug 4mm

MC4 Male Plug to suit 4-6mm² cable (5-6mm OD) with contact pin
MC-320015

MC4 Female Socket 6mm

MC4 Female Socket to suit 4-6mm² cable (5.9-8.8mm OD) with contact pin
MC-320016

MC4 Female Socket 10mm

MC4 Female Socket to suit 10mm² cable (5.9-8.8mm OD) with contact pin
320 034

MC4 Male Plug 10mm

MC4 Male Plug to suit 10mm² cable (5.9-8.8mm OD) with contact pin
320 035

MC4 Male Plug 6mm

MC4 Male Plug to suit 4-6mm² cable (5.9-8.8mm OD) with contact pin
MC-320017

MC4 Y Branch Connector

MC4 Y Connector (1 x male - 2 x female)
MC-320018

MC4 Y Branch Connector

MC4 Y Connector (2 x male - 1 x female)
MC-320019

MC4 Female Socket 2.5mm

MC4 Female Socket to suit 2.5mm² cable (5-6mm OD) with contact pin
MC-320010

MC4 Male Plug 2.5mm

MC4 Male Plug to suit 2.5mm² cable (5-6mm OD) with contact pin
MC-320011

MC4 Male Panel Mount Connector

MC4 Male Panel Mount (4-6mm²)
MC-32.0079P0001

MC4 Assembly Spanner

MC4 Assembly Spanner (set of 2pcs)
MC-326024

MC4 Securing Socket

Securing Socket for MC4 Solar Connectors (PV-SSE-AD4)
MC-326026

MC4 Tightening Socket

Tightening Socket for MC4 Connectors (PV-WZ-AD/GWD)
MC-326006

MC4 15A 1500V Inline Fuse

MC4 Inline Fuse Solar Cabe Connector suitable for String protection
PV-ILF.15.MC4TUV

MC4 Pins for Female Connector

Extra Pins for MC4 Female Connectors
MC-32.0107P0001

MC4 Pins for Male Connector

Extra Pins for MC4 Male Connectors
MC-32.0507P0001

MC4 Female to MC3 Male Adapter

MC4 Female to MC3 Male adapter (200mm)
MC-326096

MC4 Male to MC3 Female Adapter

MC4 Male to MC3 Female adapter (200mm)
MC-326097
